EZgrea Lithium soap thickener
Description

Lithium soap thickener, is prepared by selected and finely filtered materials, according to pre-designed formulation ,under clean room and via saponification,dehydration, dispersion process.Using lithium soap thickener, users can make their lithium soap grease easily. The high cleanliness property of this product is prerequisite of clean and pure end product, which is a basis for excellent bearing vibration characteristics.Lithium soap thickener has a characteristic of quality consistency and stability so as to reduce user’s time and cost for purchasing, storage, manufacturing, safety & environment protection. We provide fully technical support, preparing and providing proper process according to user’s facility.

Use instructions

The products are hygroscopic, they are suggested to be sealed while storing.The products tend to form lumps after long term storage, but they do not affect application, but the lump should be smashed before use.The products contain some small particulate, which are easy to float, keep the workplace ventilated and pay attention to operators' safety to prevent human inhale and dust-explosion duet to the dust accumulation.For more details, please refer to the SDS.

Direction for use of lithium thickener powder

1. 2/3 of total oil is fed into kettle, heated to 80°C, add metered thickener powder, then heated to 130°Cgradually.

2. Once temperature reaches 130°C,heated rapidly to 215°C, hold for 5 minutes.

3. Remained 1/3 oil is fed into kettle to quench,keep blending until the temperature reaches 170°C-180°C(holding for 10 minutes).

4. After 10 minutes,add additives when temperature drops to 110°C, blending and recycling for 30 minutes, using three roll mill or high pressure homogenizer to treat the grease, high pressure homogenizer pressure is recommended at no less than 20 MPa.

Specification
Specification of EZgrea Lithium soap thickener
ITEM lithium 12-hydroxystearate soap thickener Lithium stearate soap powder TESTING
Appearance White powder White powder Visual
Odor Non unpleasant smell Non unpleasant amell Olfactory
Granularity(80 sieve mesh pass),%(m/m) No less than 97 No less than 97 Weighing method
Water, %(m/m) 0.5 Max 0.5 Max ASTM D95
Typical data for the production of grease with EZgrea Lithium soap thickener
Base Oil Type 500N PAO10 500N PAO10 -
Kinematic viscosity at 40℃,mm²/s 90.64 62.49 90.64 62.49 ASTM D445
Kinematic viscosity at 100℃,mm²/s 10.42 10.29 10.42 10.29 ASTM D445
Viscosity Index 96 153 96 153 ASTM D2270
Thickener content, % 10 10 15 15 Weighing method
Worked cone penetration, 0.1mm 262 295 274 278 ASTM D217
Dropping point, ℃ 201 198 196 197 ASTM D566
Corrosion protection,T2 copper strip, 24h@100℃ Pass Pass Pass Pass ASTM D4048
Oil separation, 24h@100℃, % 2.9 3.6 3.8 4.1 ASTM D6184
Recommended dosage
Thickener\Grade 0 1 2 3
Lithium 12-hydroxystearate soap thickener, % 2-4 5-7 8-10 11-13
Lithium stearate soap powder, % 2-4 5-7 8-10 11-13
Note

Recommendation above is based on 500N base oil. Thickener structure,viscosity or type of base oil,paocess and additives

orfillers all will impact thickening capability of pre-formed thickener, it is suggested that further adjustment to be made

based on recommended dosage.
